Safe CAN
CAN-Bus Inductive Reader.
Part of the CAN-Bus Solutions for Advanced Telematics Applications.
The CAN-Bus Solutions for Advanced Telematics enable our customers to access on-board information and diagnostics for their fleets, supporting many standard and proprietary protocols such as OBDII, J1939 and others.
The CAN-Bus Inductive Reader is a cost-efficient device, that -by isolating the vehicle’s CAN-Bus and avoiding direct-wire electrical connections to it- adds an extra-level of security and overall reliability to advanced telematics solutions for heavy-vehicles (trucks and buses), machinery (agrotech, road, industrial), and light-vehicles (cars) applications.
.
General Specifications
» Supply Voltage: 5V ~ 38V
» Power Consumption:
» ~30mA
» Connector wire count: 4
Sensors
» CAN-Bus Inductive Sensor (readonly)
GPIOs and buses
» CAN-Bus Output Bus (read-only)
Operational
» Operating Temperature: -20°C ~ +70°C
Mechanical
» Dimensions: 34mm x 49mm x 5mm
» Weight: ~20g
Reliability*
» Received Packets: 99.9998%
» Received Packets without errors: 100%
* Based on 1,000,000 @ 500K packet stress tests, in a controlled laboratory test environment.
